Product Details:
Minimum Order Quantity | 1 Piece |
Frequency | 20 Khz |
Power | 150-2000W |
Capacity | 1 - 2000 ml |
Color | Grey |
Weight | 20 |
Voltage | 230V AC Single phase |
Display Type | LED |
Phase | Single |
Controller Type | Fully Automatic microprocessor control |
Model Number | ATP-150 |
Noise Level | 40 |
Temperature | RT-99 |
Automation Grade | Automatic |
Features | fully automatic |
Usage/Application | Emulsification crushing |
Operating Voltage | 220V AC 50 Hzs |
Brand | Athena Technology |
Material | Titanium Probe |
Ultrasonic Frequency | 20 |
Continues Mode | Yes |
Adjustable Pulse | YES |
Open loop | 1s , 4s , 8s |
Power Supply | AC 230, 50 Hz/60 Hz |
Programmable | 10 program set |
Temp Range | 10-99 Deg C (Temp settable) |
Timer | Digital 1 min -99 min adjustable Impulse digital closed loop |
Athena Ultrasonic Processor (Probe Sonicator):
Ultrasonic Homogenizers are recommended for homogenization and Analysis of laboratory samples that do not require traditional grinding or rotor-stator cutting techniques for processing. The ATHENA Ultrasonic Homogenizers offer precision engineering with all the necessary features to create a total system for ultrasonic disruption. In biological applications, Probe Sonicator is often used to disrupt cell membranes and release cellular contents. Probe Sonicator is also used to fragment molecules of DNA. Probe Sonicator is commonly used in nanotechnology for evenly dispersing nanoparticles in liquids and for breaking down particles to nano size.
Major Function:
Technical parameters:
Specifications:
Model | Particulars |
ATP-750 | Capacity : 25 "900ml Probe Size : 6mm / 12mm / 20 mm Ultrasonic Power : 750 W Frequency (KHz): 20 Timer : Cyclic ON / OFF |
ATP-500 | Capacity : 5 "500ml Probe Size : 3mm / 6mm / 12mm Ultrasonic Power : 500 W Frequency (KHz): 20 Timer : Cyclic ON / OFF |
ATP-250 | Capacity : 1 "300ml Probe Size : 3mm / 6mm Ultrasonic Power : 250 W Frequency (KHz): 20 Timer : Cyclic ON / OFF |
ATP-150 | Capacity : 0.1ml "200ml Probe Size : 3mm / 6mm Ultrasonic Power : 150 W Frequency (KHz): 20 Timer : Cyclic ON / OFF |
