Ultrasonic Probe Sonicator

Ultrasonic Probe Sonicator

85000 onwards INR/Piece

Product Details:

  • Equipment Materials Titanium Probe
  • Type Probe
  • Capacity 800 Kg/hr
  • Temperature Range 60 Celsius (oC)
  • Display Type LED
  • Supply Ability : 50 Piece Per Month
  • Click to view more
X

Price And Quantity

  • 1 Piece
  • 78000.00 - 120000.00 INR/Piece
  • 85000 onwards INR/Piece

Product Specifications

  • 800 Kg/hr
  • Titanium Probe
  • LED
  • Probe
  • 60 Celsius (oC)

Trade Information

  • Mumbai
  • 50 Piece Per Month
  • 1-2 Week
  • If order is confirmed we will reimburse the sample cost
  • Export good quality packing
  • All India
  • CE Certified ISO 9001:2008

Product Description

Product Details:

Minimum Order Quantity 1 Piece
Frequency 20 Khz
Power 150-2000W
Capacity 1 - 2000 ml
Color Grey
Weight 20
Voltage 230V AC Single phase
Display Type LED
Phase Single
Controller Type Fully Automatic microprocessor control
Model Number ATP-150
Noise Level 40
Temperature RT-99
Automation Grade Automatic
Features fully automatic
Usage/Application Emulsification crushing
Operating Voltage 220V AC 50 Hzs
Brand Athena Technology
Material Titanium Probe
Ultrasonic Frequency 20
Continues Mode Yes
Adjustable Pulse YES
Open loop 1s , 4s , 8s
Power Supply AC 230, 50 Hz/60 Hz
Programmable 10 program set
Temp Range 10-99 Deg C (Temp settable)
Timer Digital 1 min -99 min adjustable Impulse digital closed loop


Athena Ultrasonic Processor (Probe Sonicator):

  • Piezoelectric frequency energy converter : Lead zirconate TITANIUM
  • (PZT) pyro electric ceramics .
  • Standard probe: Titanium Alloy material Diameter (probe):
  • 3mm/6mm/ 10mm / 12mm.
  • CE & ISO 9001: 2008 Certified
  • Variable Amplitude Control
  • Micro Based, processer, Digital Display with user prompts
  • Full Function pulsar ON & OFF
  • Laboratory Jack

Ultrasonic Homogenizers are recommended for homogenization and Analysis of laboratory samples that do not require traditional grinding or rotor-stator cutting techniques for processing. The ATHENA Ultrasonic Homogenizers offer precision engineering with all the necessary features to create a total system for ultrasonic disruption. In biological applications, Probe Sonicator is often used to disrupt cell membranes and release cellular contents. Probe Sonicator is also used to fragment molecules of DNA. Probe Sonicator is commonly used in nanotechnology for evenly dispersing nanoparticles in liquids and for breaking down particles to nano size.

Major Function:

  • Auto-tuning and power control convenience for user.
  • Timer control the total working time from 1min to 99min;
  • Set TEMP as per required
  • Display the remaining time on countdown state.
  • Digital Display with Microprocessor Control
  • Programmable in 5 /10 USER Settings
  • ON/OFF impulse timer: make sure to deal with temperature sensitive sample. On and off can be choose to continue setting from 1s , 4s or 8s;
  • Automatic amplitude compensation to make the amplitude not changed following the carrying.
  • Digital operation , easy , direct type.

Technical parameters:

  • Timer: digital 1 min 90 min adjustable Power adjustable: 20%--100%, Impulse: digital closed loop, open loop: 1s, 4s, 8s
  • Piezoelectric frequency energy converter: Lead zirconate TITANIUM(PZT) pyro electric ceramics.
  • Standard probe: titanium alloy material Diameter (probe): 3mm /6mm /9-10mm /12mm.

Specifications:

Model

Particulars

ATP-750

Capacity : 25  "900ml Probe Size : 6mm / 12mm / 20 mm

Ultrasonic Power : 750 W Frequency (KHz): 20

Timer : Cyclic ON / OFF

ATP-500

Capacity : 5 "500ml Probe Size : 3mm / 6mm / 12mm

Ultrasonic Power : 500 W Frequency (KHz): 20

Timer : Cyclic ON / OFF

ATP-250

Capacity : 1 "300ml Probe Size : 3mm / 6mm

Ultrasonic Power : 250 W Frequency (KHz): 20

Timer : Cyclic ON / OFF

ATP-150

Capacity : 0.1ml "200ml Probe Size : 3mm / 6mm

Ultrasonic Power : 150 W Frequency (KHz): 20

Timer : Cyclic ON / OFF


Additional Information:

  • Item Code: ATP250
  • Pay Mode Terms: L/C (Letter of Credit),T/T (Bank Transfer),D/P,D/A,Other
  • Port of Dispatch: Mumbai
  • Production Capacity: 25 month
  • Delivery Time: 1-2 weeks
  • Packaging Details: Standard Packing
