In- Built Chiller Ultrasonic Cleaner

Product Description

In- Built Chiller Ultrasonic Cleaner is needed to keep the bath temperature controlled and below the room temperature. It has an inbuilt cooling facility and can do its task with personalized attention. It makes no damage to process liquid. This allows for digital tuning of transducers and is apt for several demanding applications. In- Built Chiller Ultrasonic Cleaner is a rugged, compact, and highly durable machine. It can work well with extensively protected electronic circuit and provide safe function. It has special tray that is utilized to drain and collect the chilled water.It has applicability for laboratory setup such as HPLC Mobile Phase, Glassware, Degassing, Filters Cleaning etc.

Product Details:

Ultrasonic Bath (Sonicator) With Chiller (Special combined model) Table Top Type

• Make : Athena
• Fully SS 304 Body & SS 304 Tank
• Digital Timer
• Operating Frequency 33+/-3 KHz
• MOC : SS
• Compressor : Emerson make
• Micro Controller based timer
• Compact, regged and highly durable systems
• With Standard supply of LID, basket etc.
• Capacity : - 10 liters
• Tank Size : 12 x 9 x 6 H
• Enclosure Size : 34 x 15 x 16
• Ultrasonic Power : 250 W

S.S. OD Cooling Coils inside tank for chilled water circulation and digital temp. controller to set temp, It consists of Chiller unit connected to SS water Storage Tank of above 15 liters capacity to reduce the water temp. to about 15 It has an inbuilt pump & re-circular unit to Circulate chilled water through the SS cooling coils and bring back to chiller unit. This is a table top model and is fitted in powder coated cabinet.

Ultrasonic Bath (Sonicator) with Chiller (Special combined model) Floor Mounted:

• Capacity : - 20 liter's (Approx)
• Tank Size : 18 x 12 x 6 H
• Enclouser Size : 26 x 20 x 36
• Ultrasonic Power : 400 W

Ultrasonic Bath (Sonicator) with Chiller (Special combined model) Floor Mounted

• Capacity : - 30 liter's (Approx)
• Tank Size : 15 x 15 x 8 H
• Enclouser Size : 23 x 23 x 36
• Ultrasonic Power : 600 W
