High Purity Nitrogen Generators

High Purity Nitrogen Generators
High Purity Nitrogen Generators
Send Inquiry
Product Code : HPNG78
Product Description

With sole aim to expand our business all across the globe, we are offering a quality examined range of High Purity Nitrogen Generators. At modern production unit, these generators are manufactured using high grade components by our adroit professionals. The offered generators can be purchased at industry leading prices from us. Moreover, the provided High Purity Nitrogen Generators are used for producing pure nitrogen in hospitals and labs.

Key Points:

  • Longer service life
  • Weather proof construction
  • Less maintenance
  • Free from defect

Specification :

Nitrogen & Zero Air Generator for GC

  • Combination Gas Generator Model- ATNA-01A of Zero Air & N2 Gases for (for Max. 5 GC'S )
  • Air Dryer timer based operation
  • N2 purifier to remove O2 & all other unwanted impurities & produces N2 upto Purging grade
  • Surge receiver with pressure regulator & valve inbuilt
  • Air Filters for removes moisture Capacity of N2 Gas: 500 ml/min at 5 Kg/cm² Capacity of Zero Air gas : 4000 ml/min at 5 Kg/cm²
  • Purity : 99.999%

Nitrogen Gas Generator for 5 GCs

  • Air Dryer timer based operation
  • N2 purifier to remove O2 & all other unwanted impurities & produces N2 upto Purging grade
  • Surge receiver with pressure regulator & valve inbuilt
  • Air Filters for removes moisture
  • N2 Generator Model -ATN-02A of N2 Gas for Maximum 5 GC`S)
  • Capacity N2 Gas :- 500 ml/min at 5 kg/cm²
  • Purity : 99.999%

Zero Air Generator Model - ATZ-01 which will required oil free Air Compressor for GC for Max. 5 G.C.'S

Capacity :- 4000ml/min at 4 kg/cm²


Method of Purification

Pressure Swing Adsorption (PSA) & Depressurization

Automatic Grade

Automatic

Brand/Make

Athena

Weight

60 kgs

Design

small compact

Flow Rate

2000ml/min

Purity

99.9999%

Voltage

220V AC 50 hzs

Color

Athena Grey

Size

compact 2 feet

Material

SS

Frequency

50Hzs

Capacity

500ml/min

Type

Gas Generator

Technical Specifications:

Specifications:

Nitrogen Gas Specification of TNA-

Zero Air Specification of

01 & TNA-01A

TNA-01 & TNA-01A

Capacity of TNA-01

500m1/min at

4000m1/min

Capacity of TNA- 01A

200m1/min

1500m1/min

ATN-02 (M)

500m1/min to 10 LPM

---

Pressure

5 kg/cm2

Moisture

<2 ppm

<2 ppm

Oxygen

<5 ppm

Total Hydro Carbon (THC)

< 0.3 ppm

< 0.3 ppm

CO & CO2

< 2 ppm

< 2 ppm

Purity

UHP / GC grade

UHP / GC grade

Micron particulates

<0.01p

<0.01p

Method of Purification

Pressure Swing Adsorption (PSA) & Depressurizations

Start up time

2 hr / programmable by timer 10 min

Electrical requirements

230 V AC, 50 Hz, 1 ph, 5 Amp
